Tired of wrestling with cramped garage conditions and inadequate lifting equipment for vehicle care and storage? The Katool KT-4H850 Parking Lift delivers a practical answer for transforming your workspace into an efficient, well-organized area. This unit handles up to 8,500 pounds, providing ample strength for the majority of standard automobiles and certain lighter pickup trucks.
Height configurations are adjustable to a maximum of 70.87 inches, while the unit's streamlined dimensions allow installation in virtually any garage environment. Elevating vehicles above ground level revolutionizes how you use available space—enabling straightforward maintenance access or creating additional room by stacking a second vehicle overhead.
Various vehicle types fit comfortably thanks to generous clearance spacing between the support columns, and the reduced minimum runway height broadens compatibility options. Practical features enhance usability: select from available power supply options, utilize the included caster kit for repositioning the lift, and take advantage of integrated drip trays along with a jack tray for tools.
On the safety front, this lift carries CE approval, incorporates multiple locking mechanisms for stable height positioning, and operates via a dependable hydraulic system. Elevate your garage or workshop's capabilities with the Katool KT-4H850.
Specifications
8500lbs lifting capacity.
CE Approved and Certified. It has adopted the 115% dynamic loading capacity standard and was 150% static loading capacity tested.
Single Point Manual Safety Lock Release
Four mechanical locking devices, a secondary lock system acts as a slack-cable device to engage in the unlikely event of cable failure.
Power side column can be installed at both sides, front or rear.
Non-skid diamond platforms and adjustable safety lock ladders.
Comes with a caster kit for moving the lift around.
Comes with three drip trays and a jack tray.
High-quality hydraulic system with 110V/60HZ/1PH or 220V/60HZ/1PH (Optional)
*Concrete thickness must be at least 3.93” (100 MM) with a 3000 PSI rating. Failure to install this lift on the proper concrete could result in serious injury or death! It is the customer’s responsibility to verify concrete thickness and strength before purchase and installation.
Lifting Capacity
8500 lbs. (3850KG )
Max. Lifting Height
70.87" / 1800mm
Lifting Time
75s Up / 40s Down
Height of Posts
83.66" / 2125mm
Width Overall
107.95" / 2742mm
Length Overall
198.43" / 5040mm (with Ramps)
Inside Columns
94.72" / 2406mm
Min. Runway Height
4.76" / 121mm
Motor
110VAC/60HZ/1PH
Net Weight
1820lbs / 826KG
Why Buy the Katool KT-4H850
Double Your Space The 71-inch lift height lets you stack vehicles, freeing up valuable floor space. With 95 inches between columns and an 81.5-inch drive-thru, it handles most cars and light trucks effortlessly.
Built Safe CE-certified with 150% static load testing. Four mechanical locks plus a backup slack-cable system ensure security. Twelve lock positions provide precise height control.
Practical Design The 4.76-inch minimum runway accommodates low-profile vehicles. Choose 110V or 220V power to match your setup. The included caster kit allows repositioning—not permanently fixed.
Professional Strength8,500-pound capacity handles compact cars to full-size trucks. Heavy-duty 3/8-inch cables and quality hydraulics deliver reliable performance.
Complete Package Includes drip trays, jack tray, and non-skid platforms. Single-point lock release for easy operation. Adjustable power column fits any garage layout.
Smart Investment Turn vertical space into storage or create an ergonomic maintenance bay. Perfect for collectors, enthusiasts, or anyone needing extra parking
